Chapter 2 Toa Disc Brake Frameset (Tongariro)
Chapter 2 Toa Disc Brake Frameset (Tongariro)
Chapter 2 Toa Disc Brake Frameset (Tongariro)
Chapter 2 Toa Disc Brake Frameset (Tongariro)

Chapter 2 Toa Disc Brake Frameset (Tongariro)


Regular price Rs. 264,800 Sale priceRs. 238,300 Save 10%
Tax included.

🚚 Delivery Estimated between 09 December and 14 December.


2-½ years in development with every detail carefully considered and meticulously executed, the TOA is the culmination of all the CHAPTER2 frames that have come before it. TOA which means “to be victorious, win” in Maori delivers an all-out, no-compromise carbon fibre race-ready frame platform designed, engineered, and manufactured to the most exacting standards.

Inspired by the TERE’s Performance All-Road DNA and the AO’s versatility, the TOA has all its cables/hoses tucked away from sight and the wind, creating an aerodynamically seamless transition between the MANA Bar and the TOA’s Kamm-Tail chassis.

Sporting a T47 Bottom Bracket for easy maintenance, the aluminium BB Shell works in unison with the high-tensile carbon carefully laid into the BB area to increase stiffness by up to 8% over the TERE. Additionally, the use of a Latex mandrel for the whole front triangle has increased the Headtube stiffness by 34% over the TERE for that out of the saddle and power to the pedals moment.

Other enhancements such as the bundled MANA Bar, Quick-Fit headset spacers, up to 32mm of tire clearance, vibration dampening Seatstays and Seatpost makes for a package that ticks all the right boxes.

  • Stiff Racing Frame: Improved Power Transfer & Precise Steering

  • Cable Integration: Improved Aerodynamics & Clean Aesthetics

  • Compact Kamm-Tail: Aerodynamic & Stiffness where Needed

  • Up to 32mm Tire Clearance: Increased Tire Options

  • Dropped Stays: Improved Compliance for Endurance Rides

  • T47 BB: Noise-free & Easy to Service

  • Disc Brakes Only: Improved Braking & Modulation

  • Frameset Only: Bespoke & Personal

  • Limited Edition: Exclusivity


Frame Specs

Carbon 100% Made in Japan by Toray®
Fork 2 Sizes XS, S (53mm offset) and M, L, XL (43mm offset)
Frame Weight 1105g (Disc) Size M +/- 3%
Fork 425g (Disc) Uncut +/- 3%
Seatpost 249g +/- 3%
Handlebar/Stem 395g (100-420mm) +/- 3%
Headset 1.5” C2 Integrated System
BB Internal T47
Electronic Shifting SHIMANO® Di2, SRAM® eTAP & Campagnolo® EPS compatible
Battery Type Di2 SM-BTR-2 & EPS V3 Battery compatible
Tire Clearance 30mm (ISO) & 32mm Practical
Brake Type Disc Only
Disc Thru-Axle Spec Flat Mount FR 12x100mm, RR 12x142mm, E-Thru M12x1.5mm
Safety Standard EN ISO 4210:2014


Torque Specs

Saddle Rail 6Nm
MANA 18-0Nm
Stem (Steerer)  6Nm
Front derailleur hanger 3-4Nm
Rear Derailleur Hanger 2-3Nm
BB Cable Guide Cover 1-2Nm
Water Bottle Cage Bolts 2-3Nm


NO Exchanges or Returns on this product.

Check our detailed Return Policy for more information.

If you need any further assistance, just reach out and we're happy to help.
