Marin DSX 700c (Blue/Orange)
Marin DSX 700c (Blue/Orange)
Marin DSX 700c (Blue/Orange)
Marin DSX 700c (Blue/Orange)

Marin DSX 700c (Blue/Orange)

733960003

Regular priceRs. 61,999
/
Tax included.

🚚 Delivery Estimated between 09 December and 14 December.

Description

The DSX is the mountain biker’s gravel bike with familiar hand positioning, reliable 1x drivetrains, large tire clearance, and dropper post routing for better off road control, and on road descending stability.

Specifications
  • Intended Use- Gravel
  • Wheel Size- 700c
  • Braking System- Hydraulic Disc
  • Frame Material- Aluminium
  • Fork Material- Aluminium
Components
  • Frame- Series 2 DSX, 6061 Aluminum, Internal Cable Routing, Mudguard and Rack Mounts, IS Disc Mount
  • Fork- 6061 Aluminum, Straight-Blade, Disc Mount, Fender and Rack Eyelets
  • Bottom Bracket- Sealed Cartridge Bearings, Square Taper
  • Chain- KMC X9
  • Crank- Alloy Crank, Steel Narrow-Wide Chainring, 38T
  • Shift Levers- MicroSHIFT Advent 9 Trail
  • Cassette- SunRace 9-Speed, 11-46T
  • Rear Derailleur- MicroSHIFT Advent 9, Clutch
  • Grips/Bartape- Marin MTB
  • Handlebar- Marin MiniRiser
  • Stem- Marin 3D Forged Alloy
  • Saddle- Marin DSX
  • Seatpost- Marin Alloy
  • Front Brake- Tektro HD-M275 Hydraulic Disc, 160mm Rotor
  • Rear Brake- Tektro HD-M275 Hydraulic Disc, 160mm Rotor
  • Front Wheel- Marin Aluminum Double Wall, Disc Specific
  • Rear Wheel- Marin Aluminum Double Wall, Disc Specific
  • Tire- WTB Riddler, 700Cx45mm
  • Pedal- Commute Platform
Geometry
S M L XL
A STACK 544.4 572.5 600.6 628.7
B REACH 380 405 420 435
C HEADTUBE ANGLE 69.5° 69.5° 69.5° 69.5°
D HEADTUBE LENGTH 120 150 180 210
E SEATTUBE ANGLE 74° 74° 74° 74°
F SEATTUBE LENGTH 430 480 520 558
G TOPTUBE EFFECTIVE 536.1 569.2 592.2 615.3
H BB HEIGHT 279.5 279.5 279.5 279.5
I BB DROP 80 80 80 80
J CHAINSTAY 425 425 425 425
K WHEELBASE 1024.42 1060 1085.4 1110.9
L STANDOVER HEIGHT 658.76 700.51 730.39 758.5
M FORK OFFSET 50 50 50 50
SEATPOST DIAMETER 27.2 27.2 27.2 27.2
HANDLEBAR WIDTH 640 680 680 680
STEM LENGTH 70 70 70 70
CRANK LENGTH 170 175 175 175
