Marin Stinson ST 1 27.5er (Maroon)
Marin Stinson ST 1 27.5er (Maroon)
Marin Stinson ST 1 27.5er (Maroon)
Marin Stinson ST 1 27.5er (Maroon)
Marin Stinson ST 1 27.5er (Maroon)

Marin Stinson ST 1 27.5er (Maroon)

732449002

Regular priceRs. 40,999
/
Tax included.

🚚 Delivery Estimated between 09 December and 14 December.

Description

The Stinson is an updated take on the classic cruiser design for casual and comfortable path riding. Comfort Control Geometry allows riders to touch the ground with their foot for confident and safe riding and stopping.

Specifications
  • Intended Use- Commuting
  • Wheel Size- 27.5"
  • Braking System- Mechanical Disc
  • Frame Material- Aluminium
  • Fork Material- Steel
Components
  • Frame- Series 1 Comfort, 6061 Aluminum, 27.5” Wheels, Disc Specific, Low-Step Design, Comfort Control Geometry, Kickstand Mount, Fender and Rack Mounts
  • Fork- CrMo Steel, Straight Blade, Disc Specific, Fender and Rack Eyelets
  • Bottom Bracket- Sealed Cartridge Bearings, Square Taper
  • Chain- KMC Z8
  • Crank- Alloy Crank, Steel 38T Chainring, Ring Guard
  • Shift Levers- Shimano Altus 7-Speed RapidFire
  • Cassette- SunRace 7-Speed, 11-34T
  • Front Derailleur-
  • Rear Derailleur- Shimano Tourney, 7-Speed
  • Grips/Bartape- Marin County
  • Handlebar- Marin Alloy, 60mm Rise, 30˚ Backsweep
  • Stem- Marin Alloy
  • Saddle- Marin Comfort
  • Seatpost- Marin Alloy, 27.2mm
  • Front Brake- Power CX7 Mechanical Disc, Shimano Pad Compatible, 160mm Rotor
  • Rear Brake- Power CX7 Mechanical Disc, Shimano Pad Compatible, 160mm Rotor
  • Front Wheel- Marin Aluminum Double Wall, Disc Specific
  • Rear Wheel- Marin Aluminum Double Wall, Disc Specific
  • Tire- Vee Tire Co. Speedster, 27.5”x2.35”, Puncture Protection
  • Pedal- Marin Comfort Platform
Geometry
S M L
A STACK 628.2 646.9 665.5
B REACH 340 355 370
C HEADTUBE ANGLE 68.5° 68.5° 68.5°
D HEADTUBE LENGTH 210 230 250
E SEATTUBE ANGLE 67° 67° 67°
F SEATTUBE LENGTH 382 406 444
G TOPTUBE EFFECTIVE 606.7 629.6 652.5
H BB HEIGHT 276.5 276.5 276.5
I BB DROP 68 68 68
J CHAINSTAY 485 485 485
K WHEELBASE 1083.9 1106.2 1128.6
L STANDOVER HEIGHT 510.57 510.57 510.57
M FORK OFFSET 40 40 40
SEATPOST DIAMETER 30.9 30.9 30.9
HANDLEBAR WIDTH 700 700 700
STEM LENGTH 45 45 45
CRANK LENGTH 170 170 175
