FX 1 Disc is a lightweight aluminum hybrid bike that looks great and feels just as good to ride. It has lots of gears so you can cruise any terrain comfortably, and powerful disc brakes give you confident stopping power, rain, or shine. It's perfect for anyone looking to get out more, do a bit of exercise, or commute to work on a versatile bike backed by a lifetime warranty.
This bike brings families together and helps you enjoy time outside
More confident braking means that bad weather doesn't have to keep you from enjoying your ride
It's versatile and does whatever you want it to do, whether that's riding for fitness, commuting, or cruising to the farmer's market to do the weekly shop
You can pair FX with your smartphone and send your ride data to your favorite fitness app when you add DuoTrap S
Like every Trek hybrid, it's backed by a lifetime warranty and supported by a wide network of retail partners
You want to ride more, and you're looking for performance where it really counts: a lightweight frame, a wide range of gearing, strong wheels and great stopping power. You also want a great value and the confidence of Trek's lifetime warranty.
A lightweight aluminum frame with internal cable routing for clean looks and protection from the elements, 16 speeds with a wide range of gearing so you can always find the right gear for your terrain, and disc brakes for stopping power in all weather conditions. Plus, strong double-walled wheels and mounts make it easy to accessorize your ride.
FX 1 Disc is a cool and versatile hybrid bike at a great value. It's built with a lightweight aluminum frame and reliable parts like sturdy wheels and disc brakes that stop on a dime in any weather. It’s perfectly suited to a variety of uses, from casual riding to exercise and commutes.
Customize your bike with fenders, racks, bottle cages, and more to make it your own.
|FRAME||Alpha Gold Aluminium, DuoTrap S-compatible, internal cable routing, flat-mount disc, rack and mudguard mounts, 135x5 mm QR
|FORK||FX Steel, flat-mount disc, rack mounts, 405 mm axle-to-crown, ThruSkew 5 mm QR
|BOTTOM BRACKET||Sealed cartridge, 68 mm
|CRANK||Forged alloy, 46/30, chainguard, 170 mm length
|SHIFT LEVERS||Shimano EF500, 8-speed
|FRONT DERAILLEUR||Shimano Tourney TY710, 34.9 mm clamp, top swing, dual pull
|CASSETTE||Shimano HG31, 11-32, 8-speed
|REAR DERAILLEUR||Shimano Altus M310
|SEATPOST||Bontrager alloy, 27.2 mm, 12 mm offset, 330 mm length
|FRONT BRAKE||Tektro MD-U310 mechanical disc, flat-mount, 160 mm rotor
|REAR BRAKE||Tektro MD-U310 mechanical disc, flat-mount, 160 mm rotor
|FRONT WHEEL||Bontrager Connection, alloy, double-wall, 32-hole, Schrader valve
|REAR-WHEEL||Bontrager Connection, alloy, double-wall, 32-hole, Schrader valve
|FRONT TIRE||Bontrager H2 Comp, wire bead, 30 tpi, 700x35c
|REAR TIRE||Bontrager H2 Comp, wire bead, 30 tpi, 700x35c
|PEDAL||Wellgo nylon platform
|Frame size letter||S||M||L||XL||XXL|
|A — Seat tube||38.1||44.5||50.8||57.2||63.5|
|B — Seat tube angle||74.5°||74.0°||73.5°||73.0°||72.0°|
|C — Head tube length||11.5||13||16||19||22|
|D — Head angle||70.5°||71.5°||71.5°||72.5°||72.5°|
|E — Effective top tube||54.2||55.7||57.1||58.7||60.1|
|F — Bottom bracket height||29.6||29.6||29.6||29.6||29.6|
|G — Bottom bracket drop||6.5||6.5||6.5||6.5||6.5|
|H — Chainstay length||45||45||45||45||45|
|I — Offset||5||5||5||5||5|
|J — Trail||7.5||6.8||6.8||6.2||6.2|
|K — Wheelbase||105.9||106||107||107||107.2|
|L — Standover||70.4||73.8||79.9||84.8||88.5|
|M — Frame reach||39.3||39.7||39.8||39.8||39.2|
|N — Frame stack||53.9||55.7||58.6||61.8||64.7|
