Trek Marlin 5 Gen 2 29er (Lithium Grey)
5255579
NEED HELP?
This product cannot be added to your shopping cart directly. Please Call or Whatsapp (+91) 80-47183232 to contact our Product Specialists for assistance.
This product cannot be added to your shopping cart directly. Please Call or Whatsapp (+91) 80-47183232 to contact our Product Specialists for assistance.
Description
Marlin 5 is a trail-worthy daily rider that's perfectly suited for everyday adventures, on and off the trail. A suspension fork, 2x8 drivetrain, and mounts for a rack and kickstand make it an ideal choice for new trail riders or anyone looking for a comfortable, stable commuter with the ruggedness of a real mountain bike.
Features
- <> It's right for you if... You're new to the trail and you’re looking for a real mountain bike that doubles as a commuter—and you want it all at an exceptional value. <> The tech you get A lightweight aluminum frame with internal routing to protect your cables and add to the bike's sleek look, 2x8 drivetrain, a wide range of gearing so you always have the right gear for your terrain, powerful hydraulic disc brakes, and a terrain-smoothing suspension fork with a lockout. <> The final word Marlin 5 is a great ride for all your adventures. But it's also versatile, and Marlin 5 is a popular ride on college campuses because the rack and kickstand mounts make it easy to accessorize and haul a load.
- Smaller frames have a top tube that dips down as it approaches the seat tube. This design makes for a lower standover height, which is good for shorter riders because it allows them to straddle their bike more easily. Larger frame sizes have a straight top tube because taller riders with longer legs typically don’t have the same issues with standover height.
- Marlin comes in seven frame sizes to suit riders of any height, and Smart Wheel Size ensures you’re on the fastest wheel that fits. The smallest sizes even come with short-reach brake levers and narrower handlebars that give smaller riders better comfort and control.
- Marlin looks and feels great. It’s packed with features usually found only on more expensive bikes, like a stylish frame with internal shift cable and brake hose routing, which can help your cables last longer by protecting them from the elements.
- It's a real mountain bike that's also perfectly suited to daily commutes, rides around campus, or just getting from A to B on any surface. Smaller frame sizes (XXS, XS, and S) have short-reach brake levers that make it easier and more comfortable for riders with smaller hands to brake confidently. Marlin models in XXS through S frame sizes have a curved top tube and a lower standover height that makes it easier for smaller riders to mount and dismount. Rack and kickstand mounts make it easy to accessorize, so your mountain bike can double as a rugged commuter. Like every model in the Marlin family, it's backed by Trek's lifetime warranty
Specifications
- Intended Use- Cross Country
- Wheel Size- 29"
- Braking System- Hydraulic Disc
- Frame Material- Aluminium
- Fork Material- Aluminium
Components
- Frame- Alpha Silver Aluminium, internal routing, chainstay disc-brake mount, rack and kickstand mount, 135x5 mm QR
- Fork- <> Size: XXS SR Suntour XCM 30, coil spring, lockout, preload, 100 mm QR, 100 mm travel, 26" wheel <> Size: XS SR Suntour XCT 30, coil spring, preload, hydraulic lockout, 42mm offset for 27.5" wheel, 100mm QR, 80mm travel <> Size: S SR Suntour XCT 30, coil spring, preload, hydraulic lockout, 42 mm offset for 27.5" wheel, 100 mm QR, 100 mm travel <> Size: M , ML , L , XL , XXL SR Suntour XCT 30, coil spring, preload, hydraulic lockout, 46mm offset for 29" wheel, 100mm QR, 100mm travel
- Bottom Bracket- Sealed cartridge, 73mm
- Chain- KMC Z8.3, 8 speed
- Crank- <> Size: XXS Prowheel TM-CY10, 36/22, 160 mm length <> Size: XS , S , M Shimano M315, 36/22, 170mm length <> Size: ML , L , XL , XXL Shimano M315, 36/22, 175mm length
- Shift Levers- Shimano Altus M315, 8 speed
- Cassette- Shimano HG200, 12-32, 8 speed
- Front Derailleur- Shimano Altus M315, 34.9mm clamp, top swing, dual pull
- Rear Derailleur- Shimano Altus M310
- Grips/Bartape-
- Handlebar- <> Size: XXS , XS Bontrager alloy, 31.8mm, 5mm rise, 690mm width <> Size: S , M , ML , L , XL , XXL Bontrager alloy, 31.8mm, 5mm rise, 720mm width
- Stem- <> Size: XXS Bontrager alloy, 31.8mm, Blendr compatible, 7 degree, 35mm length <> Size: XS Bontrager alloy, 31.8mm, Blendr compatible, 7 degree, 50mm length <> Size: S Bontrager alloy, 31.8mm, Blendr compatible, 7 degree, 60mm length <> Size: M Bontrager alloy, 31.8mm, Blendr compatible, 7 degree, 70mm length <> Size: ML , L Bontrager alloy, 31.8mm, Blendr compatible, 7 degree, 80mm length <> Size: XL , XXL Bontrager alloy, 31.8mm, Blendr compatible, 7 degree, 90mm length
- Saddle- Bontrager Arvada, steel rails, 138 mm width
- Seatpost- <> Size: XXS Bontrager alloy, 31.6 mm, 12 mm offset, 300 mm length <> Size: XS , S , M Bontrager alloy, 31.6mm, 12mm offset, 330mm length <> Size: ML , L , XL , XXL Bontrager alloy, 31.6mm, 12mm offset, 400mm length
- Front Brake- Tektro HD-M275 hydraulic disc
- Rear Brake- Tektro HD-M275 hydraulic disc
- Front Wheel- <> Size: XS , S Bontrager Connection, double-wall, 32-hole, 20 mm width, Schrader valve, Black <> Size: M , ML , L , XL , XXL Bontrager Connection, double-wall, 32-hole, 20 mm width, Schrader valve
- Rear Wheel- <> Size: XS , S Bontrager Connection, double-wall, 32-hole, 20 mm width, Schrader valve, Black <> Size: M , ML , L , XL , XXL Bontrager Connection, double-wall, 32-hole, 20 mm width, Schrader valve
- Tire- <> Size: XXS Bontrager XR2 Comp, wire bead, 30 tpi, 26x2.20" <> Size: XS , S Bontrager XR2 Comp, wire bead, 30 tpi, 27.5x2.20" <> Size: M , ML , L , XL , XXL Bontrager XR2 Comp, wire bead, 30 tpi, 29x2.20"
- Pedal-
- Weight(Apprx)- 13.97 kg
Geometry
| Frame size number | 15.5" | 17.5" | 18.5" | 19.5" | 21.5" |
| Frame size letter | S | M | ML | L | XL |
| Wheel size | 27.5" | 29" | 29" | 29" | 29" |
| A — Seat tube | 36.8 | 41.9 | 44.4 | 47 | 52.1 |
| B — Seat tube angle | 73.5° | 71.9° | 71.9° | 71.9° | 71.9° |
| Effective seat tube angle | 73.5° | 73.0° | 73.0° | 73.0° | 73.0° |
| C — Head tube length | 9 | 9 | 9 | 10 | 12 |
| D — Head angle | 69.3° | 69.5° | 69.5° | 69.5° | 69.5° |
| E — Effective top tube | 55.5 | 60.2 | 61.8 | 63.8 | 65.9 |
| F — Bottom bracket height | 30.2 | 31 | 31 | 31 | 31 |
| G — Bottom bracket drop | 4.8 | 5.8 | 5.8 | 5.8 | 5.8 |
| H — Chainstay length | 43.8 | 43.8 | 43.8 | 43.8 | 43.8 |
| I — Offset | 4.2 | 4.2 | 4.2 | 4.2 | 4.2 |
| J — Trail | 8.8 | 9.3 | 9.3 | 9.3 | 9.3 |
| K — Wheelbase | 106.6 | 110 | 111.6 | 113.7 | 115.9 |
| L — Standover | 68.6 | 74.8 | 75.8 | 75.7 | 76.9 |
| M — Frame reach | 38.5 | 41.8 | 43.4 | 45.1 | 46.6 |
| N — Frame stack | 57.4 | 60.2 | 60.2 | 61.1 | 63 |
Additional Info
- Country of Origin: China
- MRP: Rs. 53699.00 incl., of all taxes.
MRP changes as per variant selection - Imported By: Trek Bicycle India Pvt Ltd , Ground Floor , Unit 17 & 18 , Bestech Business Center , Badshahpur Sohna Rd Hwy , Sector 48c, Gurugram , Haryana - 122001 , India.
- Net Quantity: 1N
- Customer Care Address: 291, 10 Main, 5 Block, Jayanagar, Bangalore - 560041. Ph: (080)47183232, Email: support@bumsonthesaddle.com
- Commodity: Bicycles
