X-Caliber 8 is a cross-country mountain bike made for fast laps and long days on the trail. It's built with special attention to value and the parts that make the biggest difference in performance. A 1x Shimano drivetrain, RockShox fork and hydraulic disc brakes make it a great choice for new mountain bikers and XC racers searching for fast, fun, singletrack adventure.

Features

It's right for you if... You're looking for a fast mountain bike for singletrack – one that's fully capable of taking on races, marathons and competitive group rides. You want something that is reliable and fun with dependable, lightweight parts.
The tech you get A lightweight aluminium frame, a RockShox Judy SL 100 mm suspension fork with a TurnKey lockout and an air spring that's lighter and more adjustable than a coil spring, tubeless-ready wheels with Boost141 hub spacing and a Shimano Deore 1x12 drivetrain with a wide-range cassette.
The final word With the X-Caliber 8, you're getting a performance frame paired with performance parts, like a RockShox air fork and 1x Shimano Deore drivetrain. Plus, it's equipped with durable, lightweight alloy rims that save weight and are easy to upgrade to tubeless.
The Alpha Gold Aluminuum frame is packed with features that make your ride better. A tapered head tube gives you more precise, confident handling on the front end, while Boost 141 rear hub spacing gives you shorter chainstays for more nimble handling at the back.
X-Caliber is a classic XC hardtail with quick-handling geometry, weight-conscious parts and just enough suspension to take the edge off bumps. These models are built for efficiency, making them great for racers or anyone else who wants to cover more ground in less time.
It has the price of a more basic hardtail, but the parts and performance of a more expensive one.
The frame is fully compatible with higher-end parts, like race wheels and a dropper post, if you ever find the need to upgrade. Smart Wheel Sizing means you'll get the fastest wheel that fits (29˝ wheels on larger frames, 27.5˝ wheels on smaller frames). The 1x drivetrain delivers a wide range of gearing with the simplicity of a single shifter

Specifications

Intended Use- Cross Country
Braking System- Hydraulic Disc
Wheel Size- 27.5" /29"
Frame Material- Aluminium
Fork Material- Aluminium

Components

Frame- Alpha Gold Aluminium, tapered head tube, internal derailleur and dropper post routing, rack and kickstand mount, Boost141, 5 mm QR
Fork-
Size: XS RockShox Judy SL, Solo Air spring, TurnKey lockout, tapered steerer, 42 mm offset, Boost110, 15 mm Maxle Lite, 80 mm travel
Size: S RockShox Judy SL, Solo Air spring, TurnKey lockout, tapered steerer, Boost110, 15 mm Maxle Lite, 100 mm travel
Size: M, M/L, L, XL, XXL RockShox Judy SL, Solo Air spring, TurnKey lockout, tapered steerer, 42 mm offset, Boost110, 15 mm Maxle Stealth, 100 mm travel
Bottom Bracket-
Size: XS, S, M, M/L, L, XL, XXL Shimano BB-MT501 BSA
Size: XS, S, M, M/L, L, XL, XXL Shimano SM-BB52, 73 mm, threaded external bearing
Chain- Shimano Deore M6100, 12-speed
Crank-
Size: XS, S, M Shimano MT511, 30T steel ring, 52 mm chainline, 170 mm length
Size: M/L, L, XL, XXL Shimano MT511, 30T steel ring, 52 mm chainline, 175 mm length
Shift Levers- Shimano Deore M6100, 12-speed
Cassette- Shimano Deore M6100, 10-51, 12-speed
Rear Derailleur- Shimano XT M8100, long cage
Grips/Bartape- Bontrager XR Trail Comp, nylon lock-on
Handlebar-
Size: XS Bontrager alloy, 31.8 mm, 5 mm rise, 690 mm width
Size: S, M Bontrager alloy, 31.8 mm, 5 mm rise, 720 mm width
Size: M/L, L, XL, XXL Bontrager alloy, 31.8 mm, 15 mm rise, 750 mm width
Stem-
Size: XS, S Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 60 mm length
Size: M, M/L Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 70 mm length
Size: L Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 80 mm length
Size: XL, XXL Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 90 mm length
Saddle- Bontrager Arvada, steel rails, 138 mm width
Seatpost-
Size: XS, S Bontrager alloy, 31.6 mm, 12 mm offset, 330 mm length
Size: M Bontrager alloy, 31.6 mm, 12 mm offset, 360 mm length
Size: M/L, L, XL, XXL Bontrager alloy, 31.6 mm, 12 mm offset, 400 mm length
Front Brake- Shimano MT200 hydraulic disc
Rear Brake- Shimano MT200 hydraulic disc
Front Wheel-
Size: XS, S Bontrager Kovee, double-wall, Tubeless Ready, 28-hole, 23 mm width, Presta valve
Size: M, M/L, L, XL, XXL Bontrager Kovee, double-wall, Tubeless-Ready, 28-hole, 23 mm width, Presta valve
Size: M, M/L, L, XL, XXL Bontrager Kovee, double-wall, Tubeless-Ready, 32-hole, 23 mm width, Presta valve
Rear Wheel-
Size: XS, S Bontrager Kovee, double-wall, Tubeless Ready, 28-hole, 23 mm width, Presta valve
Size: M, M/L, L, XL, XXL Bontrager Kovee, double-wall, Tubeless-Ready, 28-hole, 23 mm width, Presta valve
Size: M, M/L, L, XL, XXL Bontrager Kovee, double-wall, Tubeless-Ready, 32-hole, 23 mm width, Presta valve
Tire-
Size: XS, S Maxxis Ardent Race, tubeless, EXO casing, folding bead, 60 tpi, 27.5x2.35"
Size: M, M/L, L, XL, XXL Maxxis Ardent Race, tubeless, EXO casing, folding bead, 60 tpi, 29x2.35"
Pedal-
Size: XS, S, M, M/L, L, XL, XXL VP-536 nylon platform
Weight(Apprx)- 13.05 kg

Geometry

Frame size number	13.5	15.5	17.5	18.5	19.5	21.5	23
Frame size letter	XS	S	M	ML	L	XL	XXL
Wheel size	27.5"	27.5"	29"	29"	29"	29"	29"
A — Seat tube	34.3	36.8	41.9	44.4	47	52.1	55.9
B — Seat tube angle	73.5°	73.5°	71.9°	71.9°	71.9°	71.9°	71.9°
Effective seat tube angle	73.5°	73.5°	73.0°	73.0°	73.0°	73.0°	73.0°
C — Head tube length	9	9	9	9	10	12	12
D — Head angle	69.3°	69.3°	69.5°	69.5°	69.5°	69.5°	69.5°
E — Effective top tube	54.4	55.5	60.1	61.7	63.7	65.8	67.2
F — Bottom bracket height	29.2	30.2	31.1	31	31	31	31.1
G — Bottom bracket drop	5.8	4.8	5.8	5.8	5.8	5.8	5.8
H — Chainstay length	42.5	42.5	43.8	43.8	43.8	43.8	43.8
I — Offset	4.2	4.2	4.2	4.2	4.2	4.2	4.2
J — Trail	8.8	8.8	9.4	9.4	9.4	9.4	9.4
K — Wheelbase	103.6	105.3	110.9	112.5	114.5	116.7	118.1
L — Standover	69.8	72.4	74.8	75.7	75.7	76.8	80.4
M — Frame reach	37.6	38.5	41.8	43.4	45.1	46.6	48
N — Frame stack	56.5	57.4	59.8	59.8	60.8	62.7	62.7

Additional Info

Country of Origin: China
Imported By: Trek Bicycle India Pvt Ltd , Ground Floor , Unit 17 & 18 , Bestech Business Center , Badshahpur Sohna Rd Hwy , Sector 48c, Gurugram , Haryana - 122001 , India.
Net Quantity: 1N
Customer Care Address: 291, 10 Main, 5 Block, Jayanagar, Bangalore - 560041. Ph: (080)47183232, Email: support@bumsonthesaddle.com
Commodity: Bicycles
